This hand dryer is a high-performance solution designed for rapid and hygienic hand drying in demanding environments. Constructed from brushed stainless steel, the unit features a compact form factor measuring 278mm in height, making it ideal for installations where spatial efficiency is a priority. The device is powered by a 200W brushless DC motor capable of reaching 18,000 rpm, delivering an impressive air speed of 75m/s to achieve drying times of under 10 seconds.
Technical excellence is demonstrated through the integration of an adjustable intelligent heating element ranging from 0 to 600W, which optimizes energy consumption while maintaining user comfort. The system operates on a 220V-240V AC supply and includes an infrared automatic circuit for touch-free operation, ensuring a sanitary experience. Safety is prioritized with an auto-resetting thermal protection thermostat that activates at 95 degrees Celsius and a 60-second auto shut-off timing protection mechanism to prevent prolonged activation.
Engineered for high-traffic applications, this unit boasts a usage capacity exceeding 500 dries per day, providing a cost-effective alternative that can reduce annual operational costs by up to 85% compared to conventional drying methods. The product is Class I rated and features an IPX2 rating, ensuring reliable performance in restroom environments. It is fully compliant with CE, WEEE, and Greenspec standards, and meets AS1428 disability compliance requirements when installed at the specified height.
Installation is streamlined via a standard 3-pin plug and lead connection, facilitating easy integration into existing electrical infrastructures. The hand dryer operates at a controlled noise level of 70dB, balancing powerful airflow with acoustic management. With a comprehensive warranty covering three years for parts and one year for labour, this stainless steel hand dryer represents a durable and energy-efficient investment for modern commercial facilities.
PRODUCT TYPE: Hand Dryer
WARRANTY: 3 years parts, 1 year labour
COMPLIANCE: CE; WEEE; Greenspec; Suitable for disabled-accessible washrooms when installed in accordance with AS 1428 requirements
COLOUR: Stainless steel
MATERIAL: Brushed stainless steel
IP RATING: IPX2
VOLTAGE: 220V-240V AC (50Hz)
WATTAGE: 800W
DIMENSIONS: 278mm (height) x 228mm (width) x 154mm (depth)
WEIGHT: 3.3kg
CLASS: I
NOISE: 70dB
AIR SPEED: 75m/s; 85 m³/h
MOTOR: 18,000 rpm; 200W; BLDC brushless DC
HEATER ELEMENT: Adjustable intelligent heating 0-600W
HEATER THERMAL PROTECTION: Auto resetting thermostat turns off at 95°C
DRYING TIME: Under 10 seconds
CIRCUIT OPERATION: Infrared automatic; self adjusting
SENSOR RANGE: 100mm
TIMING PROTECTION: 60 seconds auto shut off
POWER CONNECTION: 3-pin plug and lead
USAGE CAPACITY: Up to 500+ dries a day
FEATURES: Energy efficient; compact and cost effective; save up to 85% of annual costs compared to conventional dryers; touch free operation
REMARKS: Fast, hygienic way to dry your hands; compact size for environments where space is at a premium
INSTRUCTIONS: Includes manual and mounting guide
