This hand dryer is a high-performance surface-mounted solution engineered from 1.5mm 304-grade stainless steel with a satin finish for superior durability and aesthetic integration. The unit features a slimline design with dimensions of 283mm in height, 268mm in width, and a depth of 100mm, ensuring compliance with AS1428.1 accessibility guidelines when installed correctly. It operates on a standard 230V-240V AC supply and utilizes an automatic infrared sensor with a detection range of 80-300mm for touchless activation.
Technical performance is characterized by an adjustable power output ranging from 2200W to 2400W, facilitating a rapid drying time of less than 15 seconds through an air speed of 24m/s and a warm air output of 314.5m³/h. The internal motor operates at 7,500 RPM, while the 2200W heating element maintains a warm air temperature of approximately 20°C above ambient levels. Despite its high-velocity output, the unit maintains a controlled acoustic profile of 70dB, making it suitable for various commercial and public environments.
Safety and longevity are prioritized through a comprehensive suite of protective features, including a 60-second power cut-off with auto-reset and an auto-resetting thermostat. The device boasts an operational lifespan of 50,000 hours and carries an IP21 rating for indoor applications. It is fully compliant with international standards including CE, UL, EMC, LVD, and RoHS, reflecting its rigorous engineering and manufacturing quality.
Installation flexibility is provided by the option to either hard-wire the unit or utilize the included cord and plug, while security is enhanced by two theft-resistant hex drive screws. The product is backed by a comprehensive 5-year warranty, covering three years for full replacement or repair and an additional two years for parts. This robust hand dryer represents a reliable, energy-efficient choice for facilities requiring high-traffic drying solutions with minimal maintenance requirements.
PRODUCT TYPE: Hand Dryer
WARRANTY: 5 years (incorporating 3 years for replacement or repair and 2 further years for parts only)
COMPLIANCE: AS1428.1; CB; CE; UL; EMC; LVD; WEEE; RoHS; ISO 14001:2015; GreenSpec LISTED
COLOUR: Satin stainless steel
MATERIAL: 304 stainless steel (1.2mm thickness considered heavy gauge and premium - up to 50% thicker than typical 0.8mm alternatives)
IP RATING: IP21 (indoors only)
VOLTAGE: 230V-240V AC (50/60Hz)
WATTAGE: 2200W-2400W (adjustable)
DIMENSIONS: 283mm (height) x 268mm (width) x 100mm (depth)
WEIGHT: 4.5kg
MOUNTING: Surface mounted
LIFESPAN: 50,000 hours
OPERATION: Automatic infrared sensor; auto resetting thermostat turns unit off at 87°C; thermal fuse cuts unit off at 141°C
NOISE: 70dB (+/- 3)
INSTALLATION: Hardwired or cord and plug (hex key supplied) - if hardwired then 80mm from the connection point to the wall; if cord and plug then 80mm from the connection point to the bottom of the unit
AIR SPEED: 24m/s (53MPH)
MOTOR CUT-OFF TIME: 60-sec power cut off (auto reset)
MOTOR SPEED: 7,500 RPM
ENERGY CONSUMPTION: 9.16Wh-10Wh per day
SENSOR RANGE: 80-300mm
DRYING TIME: Less than 15 seconds
HEATER ELEMENT: 2200W @ 240Vac
WARM AIR OUTPUT: 314.5m³/h (185 CFM)
WARM AIR TEMPERATURE: Ambient +20°C
CASE SECURITY: 2 stainless-steel theft-resistant hex drive screws
FEATURES: Slimline design; accessible compliant when installed in accordance with AS1428.1 guidelines
INCLUDES: Full instruction manual, installation manual and maintenance manual
