This hand dryer is a sophisticated 3-in-1 recessed unit engineered from high-grade 304 stainless steel, featuring seamless welds and rolled edges for a superior architectural finish. Designed for high-traffic environments, this integrated system combines an automatic hand dryer, a paper towel dispenser, and a 21L removable waste container into a single streamlined assembly. The unit is specifically designed for recessed mounting to optimize space and is fully compliant with AS1428.1 guidelines for accessible installations when correctly positioned.
Technically specified for high performance, the integrated hand dryer operates at 1000W and delivers a high-velocity airflow of 90m/s, achieving a drying time of less than 15 seconds. The internal heater includes an 85°C auto-reset safety cut-off mechanism to ensure thermal protection during continuous operation. Operating at a noise level of 72dB at one meter, the device provides a balance of power and acoustic comfort, while the IP24 rating ensures protection against water splashes in commercial washroom settings.
The structural integrity of the unit is maintained through its robust stainless steel construction and a secure case fitted with a specialized security lock and dual keys. The electrical configuration supports a voltage range of 230V-240V at 50/60Hz and is designed for hard-wired installation with four available cable entry points for flexible mounting. The paper towel dispenser is optimized for standard commercial slim paper towels, ensuring compatibility with common consumables while maintaining a high-capacity waste disposal solution.
Reliability is supported by a comprehensive warranty structure, including a five-year term for the hand dryer component and a one-year term for the paper towel and waste receptacle elements. This unit represents a durable and hygienic solution for modern facility management, combining automatic sensor-driven operation with manual dispensing options. Its satin stainless steel finish provides a contemporary aesthetic that resists corrosion and maintains its professional appearance under rigorous daily use in public or commercial infrastructure.
PRODUCT TYPE: 3-in-1 Hand Dryer + Towel Dispenser + Waste Receptacle
ACCESSIBILITY: Yes (Suitable for accessible installations when installed in accordance with AS1428.1 guidelines)
WARRANTY: 5 years hand dryer (3 years for replacement or repair plus 2 further years for parts only); 1 year for paper towel dispenser and waste receptacle
COMPLIANCE: AS1428.1
COLOUR: Satin stainless steel
MATERIAL: 304 grade stainless steel
IP RATING: IP24 (protected against water splashes from any direction)
VOLTAGE: 230V-240V (50/60Hz)
WATTAGE: 1000W
DIMENSIONS: 1500mm (height) x 318mm (width) x 190mm (depth)
WALL OPENING: 1472mm (height) x 290mm (width) x 192mm (depth)
MOUNTING: Recessed
NOISE: 72dB (+/-3) @1m
DRYING TIME: Less than 15 seconds
DISPOSAL: 21L removable stainless steel waste container
POWER SUPPLY: Hard wired - 4 electrical cable entry points available
HEATER: 85°C auto reset safety cut off
WARM AIR: Speed: 90m/s; Temp: Ambient +25°C
PAPER TOWELS: Requires standard size commercial slim paper towels (sold separately)
CASE SECURITY: Unit fitted with security lock; unit is supplied with 2 keys
FEATURES: Seamless welds; rolled edges; automatic operation; auto dryer
INCLUDES: Full instruction manual, installation manual and maintenance manual
