This hand dryer is a high-performance solution engineered for high-traffic environments such as airports, large hotels, and sports centers. Constructed with a 1.5mm thick bright stainless steel cover and a fire-resistant plastic base, the unit ensures durability and resistance to vandalism in demanding public spaces. The device utilizes a universal brush motor operating at 4,500 RPM to deliver an effective airflow of 450 cubic meters per hour and an air speed of 95 kilometers per hour, facilitating a drying time of approximately 29 seconds.
Technical precision is maintained through the integration of Logic Dry technology, which automatically regulates the outlet air temperature across four distinct levels to optimize energy efficiency and user comfort. The system features an adjustable infrared electronic detection sensor with a range of 5 to 25 centimeters, allowing for touchless operation that initiates upon hand detection and ceases two seconds after removal. Safety is prioritized with the inclusion of thermal limiters in both the 2,500W NiCr heating element and the motor, alongside a safety thermal cut-off and an automatic disconnection feature after 120 seconds of continuous use.
The internal architecture comprises an aluminum fan wheel and a heating element mounted on a mica frame, supported by a Class II electrical insulation rating and an IP23 protection level. Acoustic performance is managed at 65 dBA measured at two meters, while the installation process is streamlined by a base plate featuring four 8mm mounting holes and silent blocks designed to dampen mechanical vibrations. This combination of robust materials and sophisticated electronic control systems ensures a long life cycle and reliable operation in official organizations and large recreational areas.
Operating within a voltage range of 220V to 240V at 50 or 60Hz, the unit offers adjustable power consumption between 250W and 2,750W to meet specific ecological energy-saving requirements. The compact dimensions of 325mm in height, 275mm in width, and 164mm in depth, coupled with a total weight of 4.25kg, allow for versatile wall-mounted applications. Certified by CE, GS, EMC, RoHS, and the CB Scheme, this hand dryer represents a technically advanced and compliant choice for modern facility management.
PRODUCT TYPE: Hand Dryer
APPLICATIONS: Airports; large hotels; sports centers; large recreational areas; official organizations
MADE IN: Europe
WARRANTY: 5 years (2 years labour, 5 years parts)
COLOUR: Bright (finish)
MATERIAL: Stainless steel AISI 304 (cover); fire resistant plastic PA 6-V0 (base and fan scroll); aluminium (fan wheel); NiCr heating element on mica frame
IP RATING: IP23
VOLTAGE: 220V-240V (50/60Hz)
WATTAGE: 250W-2,750W (adjustable)
DIMENSIONS: 325mm (height) x 275mm (width) x 164mm (depth)
WEIGHT: 4.25kg
MOUNTING: Wall mounting
CLASS: II
RPM: 4,500
MOTOR: 250W (universal brush motor)
NOISE: 65 dBA (at 2m; measured according to UNE EN ISO 11201:2010 V2)
MOTION SENSOR: Yes (fully adjustable 5cm-25cm IR electronic detection sensor by means of a potentiometer)
OPERATION: Dryer starts automatically when hands are placed under the air outlet; continues operating while hands remain within sensor detection range; stops 2 seconds after hands are removed; automatic disconnection after 120 seconds of continuous use
INSTALLATION: Base plate with 4 Ø 8 mm holes for wall mounting; includes silent blocks to damp mechanical vibrations
FEATURES: Logic Dry technology (automatically regulates outlet air temperature to 4 possible levels); anti-vandalism features; safety thermal limiters in heating element and motor; safety thermal cut-off; ecologic energy saving feature; longer life cycle
CONSUMPTION: 1.2A-12A
HEATING ELEMENT: 2,500W
COVER THICKNESS: 1.5mm
DRYING TIME: 29 seconds
EFFECTIVE AIRFLOW: 450 m³/h (7,500 L/min)
AIR SPEED: 95km/h
AIR TEMPERATURE: 50°C (at 10 cm distance/21°C)
CERTIFICATIONS: CE; GS; EMC; RoHS; CB Scheme
